SonicWall Accessories Telecommunication Equipment
Part #: 01-SSC-5515 | SKU: 35625

SonicWall Accessories Telecommunication Equipment

Part Details: Long Range Dual Band Wireless Card (Wireless Enabler)

Need a different version of the SonicWall Accessories Accessory? View all 12 configurations

Additional Information

Manufacturer	No
Model Name	Accessories
Product Condition	No

Technical Information

Wireless Technology: IEEE 802.11a/b/g
Frequency Band/Bandwidth:
- 2.4GHz
- 5GHz
Frequency Band/Bandwidth Details:
- 5.15GHz to 5.25GHz IEEE 802.11a
- 5.25GHz to 5.35GHz IEEE 802.11a
- 5.725GHz to 5.825GHz IEEE 802.11a
- 2.412GHz to 2.462GHz IEEE 802.11b/g US
Antenna: 1 x Built-in Diversity Antenna Integrated
Antenna Range:
- 180ft @11 Mbps Indoor IEEE 802.11b/g
- 130ft @ 54 Mbps Outdoors IEEE 802.11a
Transmission Speed:
- 108Mbps 2x Mode
- 96Mbps 2x Mode
- 72Mbps 2x Mode
- 54Mbps Auto-fallback IEEE 802.11a/g
- 48Mbps Auto-fallback IEEE 802.11a/g
- 36Mbps Auto-fallback IEEE 802.11a/g
- 24Mbps Auto-fallback IEEE 802.11a/g
- 18Mbps Auto-fallback IEEE 802.11a/g
- 12Mbps Auto-fallback IEEE 802.11a/g
- 9Mbps Auto-fallback IEEE 802.11a/g
- 6Mbps IEEE 802.11a/g
- 11Mbps Auto-fallback IEEE 802.11b
- 5.5Mbps Auto-fallback IEEE 802.11b
- 2Mbps Auto-fallback IEEE 802.11b
- 1Mbps IEEE 802.11b
Channels: 11 Channel(s)
Wireless Security:
- AES-CCM Encryption support Support for Windows 802.1X supplicants Wi Fi Sec (IPSec VPN) using SonicWALL's Global Security Client WPA-PSK (Pre-Shared Key) and WPA-EAP (Extensible Authentication Protocol) including EAP-TLS and EAP-PEAP Wired Equivalent Privacy (WEP) encryption, operating with 64 bit, 128 bit or 152 bit encryption with support for TKIP and AES
- AES-CCM Encryption supportSupport for Windows 802.1X supplicantsWi Fi Sec (IPSec VPN) using SonicWALL's Global Security ClientWPA-PSK (Pre-Shared Key) and WPA-EAP (Extensible Authentication Protocol) including EAP-TLS and EAP-PEAPWired Equivalent Privacy (WEP) encryption, operating with 64 bit, 128 bit or 152 bit encryption with support for TKIP and AES
Modulation:
- BPSK QPSK 1-QAM 64-QAM
- CCK BPSK QPSK
- BPSKQPSK1-QAM64-QAM
- CCKBPSKQPSK
Output Power: 20dBm
Host Interface: 32-bit CardBus PC card Type II

General Information

Manufacturer: SonicWALL
Product Name: 01-SSC-5515 Long Range Dual Band Wireless Card

Physical Characteristics

Dimensions: 0.30" (8mm) x 2.13" (54mm) x 4.65" (118mm)
Weight: 1.4 oz

Other

Package Contents:
- 01-SSC-5515 Long Range Dual Band Wireless Card One installation CD One Quick Start Installation Guide document
- 01-SSC-5515 Long Range Dual Band Wireless CardOne installation CDOne Quick Start Installation Guide document
System Requirement:
- PC/AT compatible computer with a 32-bit Cardbus PC Card Standard V7.1 Type II slot 300 MHz or higher processor 32 MB or greater memory
- PC/AT compatible computer with a 32-bit Cardbus PC Card Standard V7.1 Type II slot300 MHz or higher processor32 MB or greater memory
Additional Information:
- 802.11a operates at 63mW max output, and 802.11g radio operates at 100mW max output Transmission Power Control (TPC) support
- Status Indicators: RF link activity Ad-hoc (or peer-to-peer) for departmental or office LANs Offers flexibility to adjust RF output power Power 3.3 V Compatibility: Drivers 98SE/Me/2000/XP operating system Transmit Output: Up to 20 dBm 802.11a Up to 18 dBm 802.11g Up to 20 dBm 802.11b
- 802.11a operates at 63mW max output, and 802.11g radio operates at 100mW max outputTransmission Power Control (TPC) support
- Status Indicators: RF link activityAd-hoc (or peer-to-peer) for departmental or office LANsOffers flexibility to adjust RF output powerPower 3.3 VCompatibility: Drivers 98SE/Me/2000/XP operating systemTransmit Output:Up to 20 dBm 802.11a Up to 18 dBm 802.11gUp to 20 dBm 802.11b
Agency Approvals:
- Wi Fi certified Regulatory: FCC Part 15/UL ETSI 300/328/CE
- FCC Part 15 Class B EN55022 Class B (emissions) and Immunity
- UL 1950 CSA C22.2 No. 950
- IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.1x IEEE 802.11d Multi-country Roaming support
- Wi Fi certifiedRegulatory: FCC Part 15/ULETSI 300/328/CE
- FCC Part 15Class BEN55022 Class B (emissions) and Immunity
- UL 1950CSA C22.2 No. 950
- IEEE 802.11aIEEE 802.11bIEEE 802.11g IEEE 802.1xIEEE 802.11d Multi-country Roaming support
Software Included: SonicWALL Global VPN Client software
Platform Support: PC

Environmental Conditions

Temperature:
- 0Â°C (32Â°F) to 55Â°C (131Â°F) Operating
- -40Â°C (-40Â°F) to 70Â°C (158Â°F) Storage
Humidity: 5 to 95% Typical Non-condensing

Management

Management Tools: SonicWALL Client Utility

Warranty

Manufacturer Warranty: 1 Year(s)

Extended Details

SonicWall Accessories Telecommunication Equipment Part #: 01-SSC-5515 | SKU: 35625
