Socket Mobile Spare Parts
Part #: AC4004-253 | SKU: 83220

Product Type: PC Card Adapter
Brand Name: B&amp;B
Manufacturer: B&amp;B Electronics Mfg. Co
Product Name: Type II CompactFlash-to-PC Card Adapter
Package Type: Retail
Packaged Quantity: 20

Products and parts from Socket-Mobile.

Socket Mobile Spare Parts

Part Details: Socket Type II CompactFlash-to-PC Card Adapter - DISCONTINUED - CompactFlash Type II Media Supported - PC Card Type II

Need a different version of the Socket Mobile Mobile Computer? View all 355 configurations

Additional Information:
- Features:
- Type: Dual-row at mating section
- Temperture Range: -40 °C to +85°C (includes temperature rise in applying electrical current)
- Insulation Resistance: 1,000 M Ohm min. (500 V DC)
- Contact Resistance: Initial value/ 40Ohm max. After environmental testing/ max. 20mOhm variation from initial value
- Current rating: 0.5A AC, DC/line
- Mating/unmaking life: 10,000 cycles
- Pins: 50 pins
- Conforms to CompactFlash Adapter (CFA) standards
- Material and Finish:
- 50-pin side header: phosphor bronze, nickel-undercoated contact with gold-plated mating section and tin/leadplated solder; PPS, UL94V-0 housing
- 68-pin side socket: beryllium copper, nickel-undercoated contact with a gold-plated mating section and tin/lead plated contact; LCP, UL94V-0 housing; phosphor bronze grounding spring with nickel undercoat and gold-plating
- Copper alloy spring and synthetic resin shutter
