SIIG PC Card Products

Part Details: low profile PCI-cs (var), dual-port serial (16550) i/o card, provides a fan-out cable using only one PCI

Need a different version of the SIIG PC Card Products? View all 98 configurations

Additional Information

Manufacturer	No
Model Name	PC Card
Product Condition	No

Technical Information

Data Transfer Rate: Up to 230 Kbps
Host Interface: PCI
Buffer: 32 Byte
Baud Rate: 230 Kbps
IRQ: Sharing
Controller Type: CyberPro
Platform Supported: PC
UART Type: 16550

General Information

Product Type: Serial Adapter
Brand Name: SIIG
Packing: Box
Manufacturer: SIIG, Inc
Product Name: Low-Profile PCI-2S
Package Type: OEM
Packaged Quantity: 1

Physical Characteristics

Form Factor: Low-profile Rack-mountable

Interfaces/Ports

Ports: 2 x 9-pin DB-9 Male RS-232 Serial External

Other

Green Compliant: Yes
Green Compliance Certificate/Authority: RoHS
Package Contents:
- Low profile PCI 2S board
- Mini 2-port fan-out cable
- Driver CD
- Quick installation guide
- Low profile PCI 2S board
- Mini 2-port fan-out cable
- Driver CD
- Quick installation guide
Certifications & Standards: FCC Class B, CE, RoHS
System Requirements:
- Pentium or equivalent computer with an available 32-/64-bit PCI or PCI-X slot
- Windows 95 or later
Additional Information:
- Regulatory approval(s): FCC Class B (DoC) & CE
- RoHS-compliant
- OS support: Windows 95/98/98 SE/ME/NT4.0/2000/XP/Server 2003
- Chip: CyberPro
- Bus type: 32-bit PCI
- Port type: Two 9-pin RS232 serial ports
- IRQ sharing reduces IRQ conflicts
- Built-in 32-byte FIFO buffers dramatically increase data transmit/receive speed, especially under Windows multitasking environment
- 4-layer PCB board: separate layers for data & grounding. Greatly reduces signal noise & loss. Delivers more reliable high-speed data transfers
- Enhanced bracket design to prevent bending. Connected to PCB with washered screws for a more secure connection
- Supports 3.3V operation with 5V tolerance
- Conforms to PCI v2.2 universal card standard. PCI-X & 64-bit compatible
- Supports PME # (Power Management Event). Allows device to request a change in system power state (wake up system)
- Use SMT (Surface Mount Technology) type electrolytic capacitor. Low ESR (Equivalent Series Resistance) aluminum electrolytic capacitor. Offers much improved noise suppression & achieves higher levels of performance/reliability
- Use SMT (Surface Mount Technology) type crystal. Offers cleaner design than traditional DIP-type crystal. Provides greatly improved grounding, which reduces EMI emission & improves performance/reliability

Power Description

Input Voltage:
- 3.30 V
- 5 V

Warranty

Limited Warranty: Lifetime
