Additional Information
| Manufacturer | No |
|---|---|
| Model Name | PC Card |
| Product Condition | No |
Technical Information
- Data Transfer Rate: Up to 230 Kbps Serial Port
- Host Interface: Universal PCI
- Baud Rate: 230 Kbps
- IRQ: IRQ sharing feature eliminates IRQ conflicts
- Controller Type: CyberPro
- Parallel Port Modes:
- EPP/ECP
- BPP
- SPP
- Platform Supported: PC
- UART Type: 16550
General Information
- Product Type: Serial/Parallel Combo Adapter
- Brand Name: SIIG
- Packing: Box
- Manufacturer: SIIG, Inc
- Product Name: Low Profile PCI-1S1P
- Package Type: OEM
- Packaged Quantity: 1
Physical Characteristics
- Height: 3.1"
- Width: 0.7"
- Form Factor: Low-profile Plug-in Card
Interfaces/Ports
- Ports:
- 1 x 9-pin DB-9 RS-232 Serial
- 1 x 25-pin DB-25 IEEE 1284 Parallel
Other
- Green Compliant: Yes
- Green Compliance Certificate/Authority: RoHS
- Package Contents:
- Low Profile PCI-1S1P Serial Parallel Combo Adapter
- 1S1P port fan-out cable
- Driver CD
- Installation Guide
- Low Profile PCI-1S1P Serial Parallel Combo Adapter
- 1S1P port fan-out cable
- Driver CD
- Installation Guide
- Certifications & Standards:
- FCC Class B (DoC)
- CE
- IEEE 1284-1994
- RoHS
- System Requirements:
- Pentium or equivalent computer with an available 32-/64-bit PCI or PCI-X slot
- Windows 95 or later
- Additional Information:
- Regulatory approval(s): FCC Class B (DoC) & CE
- RoHS compliant
- OS support: Windows 95/98/98 SE/ME/NT4.0/2000/XP/Server 2003/Vista (32-bit)
- Chip: CyberPro
- Bus type: 32-bit PCI
- Port type: One 9-pin RS232 serial port & one 25-pin ECP/EPP parallel port
- IRQ sharing reduces IRQ conflicts
- Built-in 32-byte serial port FIFO buffers dramatically increase data transmit/receive speed, especially under Windows multitasking environment
- 4-layer PCB board: separate layers for data & grounding. Greatly reduces signal noise & loss. Delivers more reliable high-speed data transfers
- Enhanced bracket design to prevent bending. Connected to PCB with washered screws for a more secure connection
- Supports 3.3V operation with 5V tolerance
- Conforms to PCI v2.2 universal card standard. PCI-X & 64-bit compatible
- Supports PME # (Power Management Event). Allows device to request a change in system power state (wake up system)
- Use SMT (Surface Mount Technology) type electrolytic capacitor. Low ESR (Equivalent Series Resistance) aluminum electrolytic capacitor. Offers much improved noise suppression & achieves higher levels of performance/reliability
- Use SMT (Surface Mount Technology) type crystal. Offers cleaner design than traditional DIP-type crystal. Provides greatly improved grounding, which reduces EMI emission & improves performance/reliability
Warranty
- Limited Warranty: Lifetime
Power Description
- Input Voltage: 3.30 Vto 5 V
