Intermec Barcode Label Printer & Intermec Barcode Scanner

Intermec Barcode Label Printer
Part #: PM43A01000000301 | SKU: INT177441

PM43 mid-range industrial printers are ideal for a wide range of applications within the distribution center/warehouse and manufacturing environments.The PM4 is a third-generation Intermec industrial printer designed to maximize your uptime. Count on it to deliver quick deployment, the fastest print speed in its class, and proven reliability.

Intermec Barcode Label Printer

Part Details: Industrial Thermal transfer Printer, 300 dpi, Interface Options usb, serial, Ethernet, Maximum Print width 4.17 inches., Hanger, US Power cord

Need a different version of the Honeywell PM43 Barcode Label Printer? View all 58 configurations

Additional Information

Filter	No
Included Features	No
Interface Options	Ethernet, USB
Label Core	No
Manufacturer	Intermec
Max Label Width	4.50
Max Roll Outer Diameter	8
Maximum Print Width	4.25
Model Name	PM43
Print Method	No
Print Resolution	No
Print Speed	12
Printer Mobility	No
Printer Type	Industrial
Product Condition	No
Ribbon Core	1

Intermec PM43 Specs (pdf)

Technical Information

Maximum Mono Print Speed: 12 in/s
Maximum Print Resolution: 300 dpi
Print Color: Monochrome
Maximum Print Width: 4.17"
Recommended Use: Label Print
Barcode Symbology Supported:
- UPC/EAN Shipping Container
- UCC/EAN 128 Serial Shipping Container
- LOGMARS
- POSTNET
- HIBCC
- ISBT-128
- GM1724

General Information

Product Type: Direct Thermal/Thermal Transfer Printer
Product Series: PM
Brand Name: Intermec
Manufacturer: Intermec Technologies Corporation
Product Model: PM43
Product Name: PM43 Mid-Range Printer

Physical Characteristics

Height: 11.6"
Width: 11.2"
Depth: 19"
Form Factor: Desktop
Weight (Approximate): 34.88 lb

Interfaces/Ports

USB: Yes
Serial Port: Yes

Media Types & Handling

Maximum Label Width: 4.50"
Media Type:
- Label
- Tag
- Linered Label
- Linerless
- Roll Fed
- Fanfold
- Gap
- Notch
- Black Mark
- Continuous Label
Media Thickness: 10.40 mil
Media Sensor: Transmissive Media Sensor
Label Core Size: 3"
Ribbon Core Size: 1"
Maximum Roll Diameter: 8.38"

Other

Green Compliant: Yes
Green Compliance Certificate/Authority:
- ENERGY STAR
- RoHS
Platform Supported: PC
Certifications & Standards:
- PFC Regulation: IEC320/C14
- CE (EN55022 Class A)
- FCC Class A
- UL/cUL
- C-Tick
- D Mark
- CCC

Power Description

Input Voltage:
- 110 V AC
- 220 V AC
Standby Power Consumption: 9 W
Maximum Power Consumption: 300 W
Power Source: AC Supply

Fonts & Emulation

Language Emulation:
- Fingerprint
- IPL
- ZSim
- DSim
- XML

Memory

Standard Memory: 128 MB
Memory Technology: SDRAM
Flash Memory: 128 MB

Network & Communication

Ethernet: Yes
Ethernet Technology: Fast Ethernet

Warranty

Limited Warranty: 1 Year

Extended Details

Barcode Discount

Intermec Barcode Label Printer Part #: PM43A01000000301 | SKU: INT177441
