Additional Information
| Manufacturer | Cisco |
|---|---|
| Model Name | Accessories |
| Product Condition | No |
General Information
- Product Type: Network Module
- Brand Name: Cisco
- Manufacturer: Cisco Systems, Inc
- Product Name: Network Module
Technical Information
- Application/Usage: Data Networking
Physical Characteristics
- Dimensions: 1.6" Height x 7.1" Width x 7.2" Depth
- Weight (Approximate): 2.50 lb Maximum -
Interfaces/Ports
- Interfaces/Ports: 1 x 10/100Base-TX LAN
- Interfaces/Ports Details: 1 x RJ-45 10/100Base-TX Auto-sensing, Half/Full-duplex LAN
Other
- Compatibility:
- Cisco 2691
- Cisco 3620
- Cisco 3640
- Cisco 3660
- Cisco 3725
- Cisco 3745
- Compatible with all existing network modules and WICS supported by Cisco 2600/3600 family<br><br>
- Supported Platforms & Minimum IOS Versions:
- 3745 - 12.2(13)T
- 3725 - 12.2(13)T
- 3660 series - 12.2(13)T
- 3640 - 12.2(13)T
- 3620 - 12.2(13)T
- 2691 - 12.2(13)T
- 2600XM Series - Not Supported
- 2600 series - Not Supported
- Cisco 2691
- Cisco 3620
- Cisco 3640
- Cisco 3660
- Cisco 3725
- Cisco 3745
- Compatible with all existing network modules and WICS supported by Cisco 2600/3600 family<br><br>
- Supported Platforms & Minimum IOS Versions:
- 3745 - 12.2(13)T
- 3725 - 12.2(13)T
- 3660 series - 12.2(13)T
- 3640 - 12.2(13)T
- 3620 - 12.2(13)T
- 2691 - 12.2(13)T
- 2600XM Series - Not Supported
- 2600 series - Not Supported
- Certifications & Standards:
- Regulatory Approvals:
- UL 1950
- EMI:
- FCC Part 15 Class B - CISPR 22 Class B
- System Requirements:
- Minimum level IOS is 12.2(12)M and 12.2(13)T
- The Maximum Number of NMs that can be utilized in each of the 2600/3600 families
- Cisco 2691: 1
- Cisco 3620: 2
- Cisco 3640: 4
- Cisco 3660: 6
- Cisco 3725: 2
- Cisco 3745: 4
- Additional Information:
- WAN cables dependant on WICs. LAN interfaces have 10/100BaseT cables for Ethernet and STP/UTP cables for Token Ring
- LAN-to-LAN Routing
- Serial & Legacy Concentration
- VWICs in data mode only<br>
- Max T1/E1 WIC Connections: 4
- VWIC Support: Full
- WIC Support: Full
- WIC Throughput: 8Mb
- TDM Support: Yes
- Ethernet Support: 10/100Mb
- G.703 WIC Support: Yes
- Full Duplex Token Ring: Yes<br>
- 2620 with 2 BRI and Serial Backup: 2620+2BRI WIC+NM-2W+1T WIC
- 3620 with FE LAN and 2 Serial Connections: 3620+1FE2W+2T WIC
- 3640 with 2 FE LAN and 8 BRI with 2 Serial Backup: 3640+2FE2W+8BRI NM+2T WIC
- 3660 with 4 FE LAN with 8Mb Serial Backup: 3660+2FE2W+2TWIC<br>
- WIC Performance Up to 8Mb/s per WIC (with just 1 WIC installed)
Environmental Conditions
- Humidity: 5% to 95% Relative Humidity
- Temperature:
- 32°F (0°C) to 104°F (40°C) Operating
- -13°F (-25°C) to 158°F (70°C) Non-operating
Media & Performance
- Data Transfer Rate:
- 10 Mbps Ethernet Half-duplex
- 100 Mbps Fast Ethernet Half/Full-duplex
- Connectivity Media: STP/UTP 10/100Base-TX
Controls/Indicators
- Status Indicators:
- Token ring 4/16 speed indication
- Ethernet 10/100 Speed Indication
- Link and full Duplex LEDS
I/O Expansions
- Expansion Slots: 2 x Expansion Slot
Warranty
- Limited Warranty: 90
Power Description
- Power Consumption: 15 W Maximum
