Cisco Accessories Accessory
Part #: HWIC-4ESW= | SKU: CIS41003

Cisco Accessories Accessory

Part Details: Four Port 10/100 Ethernet Switch Interface Card

Need a different version of the Cisco Accessories Accessory? View all 1227 configurations

Additional Information

Manufacturer	Cisco
Model Name	Accessories
Product Condition	No

General Information

Product Type:
- HWIC
- HWIC
Brand Name:
- Cisco
- Cisco
Manufacturer:
- Cisco Systems, Inc
- Cisco-IMSourcing
Product Name:
- 4-port 10/100 Ethernet Switch HWIC
- 4-port 10/100 Ethernet Switch HWIC
Product Model: HWIC-4ESW

Technical Information

Application/Usage:
- Wide Area Network
- Wide Area Network

Physical Characteristics

Dimensions:
- 0.8" Height x 3.1" Width x 4.7" Depth
- 0.8" Height x 3.1" Width x 4.7" Depth
Weight (Approximate):
- 2.79 oz
- 2.79 oz

Interfaces/Ports

Interfaces/Ports:
- 4 x 10/100Base-TX
- 4 x 10/100Base-TX
Interfaces/Ports Details:
- 4 x RJ-45 10/100Base-TX Auto-sensing/Auto-negotiating/Auto MDI/MDI-X
- 4 x RJ-45 10/100Base-TX Auto-sensing/Auto-negotiating/Auto MDI/MDI-X

Other

Compatibility:
- 1841
- 2801
- 2811
- 2821
- 2851
- 3825
- 3845
- 1841
- 2801
- 2811
- 2821
- 2851
- 3825
- 3845
- 1841
- 2801
- 2811
- 2821
- 2851
- 3825
- 3845
- 1841
- 2801
- 2811
- 2821
- 2851
- 3825
- 3845
Certifications & Standards:
- IEEE 802.3: 10BASE-T Ethernet
- IEEE 802.3u: 100BASE-TX Fast Ethernet
- IEEE 802.1d: Spanning Tree Protocol
- IEEE 802.1p: CoS for Traffic Prioritization
- IEEE 802.1q: VLAN
- IEEE 802.1x: Security
- IEEE 802.3x: Full Duplex and Flow Control
- RFC:
- RFC 2284, PPP Extensible Authentication Protocol (EAP)
- MIBs:
- RFC 1213 IF MIB
- RFC 2037 ENTITY MIB
- CISCO-CDP-MIB
- CISCO-IMAGE-MIB
- CISCO-FLASH-MIB
- OLD-CISCO-CHASSIS-MIB
- CISCO-VTP-MIB
- CISCO-HSRP-MIB
- OLD-CISCO-TS-MIB
- CISCO-ENTITY-ASSET-MIB
- CISCO-ENTITY-FRU-CONTROL-MIB
- BRIDGE MIB (RFC 1493)
- CISCO-VLAN-MEMBERSHIP-MIB
- CISCO-VLAN-IFINDEX-RELATIONSHIP-MIB
- RMON1-MIB
- PIM-MIB
- CISCO-STP-EXTENSIONS-MIB
- OSPF MIB (RFC 1253)
- IPMROUTE-MIB
- CISCO-MEMORY-POOL-MIB
- ETHER-LIKE-MIB (RFC 1643)
- CISCO-ENTITY-FRU-CONTROL-MIB.my
- CISCO-RTTMON-MIB
- CISCO-PROCESS-MIB
- CISCO-COPS-CLIENT-MIB
- IEEE 802.3: 10BASE-T Ethernet
- IEEE 802.3u: 100BASE-TX Fast Ethernet
- IEEE 802.1d: Spanning Tree Protocol
- IEEE 802.1p: CoS for Traffic Prioritization
- IEEE 802.1q: VLAN
- IEEE 802.1x: Security
- IEEE 802.3x: Full Duplex and Flow Control
- RFC:
- RFC 2284, PPP Extensible Authentication Protocol (EAP)
- MIBs:
- RFC 1213 IF MIB
- RFC 2037 ENTITY MIB
- CISCO-CDP-MIB
- CISCO-IMAGE-MIB
- CISCO-FLASH-MIB
- OLD-CISCO-CHASSIS-MIB
- CISCO-VTP-MIB
- CISCO-HSRP-MIB
- OLD-CISCO-TS-MIB
- CISCO-ENTITY-ASSET-MIB
- CISCO-ENTITY-FRU-CONTROL-MIB
- BRIDGE MIB (RFC 1493)
- CISCO-VLAN-MEMBERSHIP-MIB
- CISCO-VLAN-IFINDEX-RELATIONSHIP-MIB
- RMON1-MIB
- PIM-MIB
- CISCO-STP-EXTENSIONS-MIB
- OSPF MIB (RFC 1253)
- IPMROUTE-MIB
- CISCO-MEMORY-POOL-MIB
- ETHER-LIKE-MIB (RFC 1643)
- CISCO-ENTITY-FRU-CONTROL-MIB.my
- CISCO-RTTMON-MIB
- CISCO-PROCESS-MIB
- CISCO-COPS-CLIENT-MIB
System Requirements:
- Supported Platforms & Minimum IOS Versions:
- 3845 - 12.3(11)T
- 3825 - 12.3(11)T
- 2801 - 12.3(8)T
- 2811 - 12.3(8)T
- 2821 - 12.3(8)T
- 2851 - 12.3(8)T
- 1841 - 12.3(8)T
- Supported Platforms & Minimum IOS Versions:
- 3845 - 12.3(11)T
- 3825 - 12.3(11)T
- 2801 - 12.3(8)T
- 2811 - 12.3(8)T
- 2821 - 12.3(8)T
- 2851 - 12.3(8)T
- 1841 - 12.3(8)T
Additional Information:
- Operating Altitude: derate 1.5°C per 1000 feet
- Operating Altitude: derate 1.5°C per 1000 feet

Management & Protocols

Management:
- SNMP and Telnet interface support delivers comprehensive in-band management, and a CLI management console provides detailed out-of-band management
- Embedded Remote Monitoring (RMON) software agent supports four RMON groups (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis
- Switched Port Analyzer (SPAN) port can mirror traffic from one or many ports to another port for monitoring all nine RMON groups with an RMON probe or network analyzer
- Response Time Monitoring (RTTMON) MIB allows users to monitor network performance between the HWIC switch and a remote device
- Virtual LAN
- SNMP and Telnet interface support delivers comprehensive in-band management, and a CLI management console provides detailed out-of-band management
- Embedded Remote Monitoring (RMON) software agent supports four RMON groups (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis
- Switched Port Analyzer (SPAN) port can mirror traffic from one or many ports to another port for monitoring all nine RMON groups with an RMON probe or network analyzer
- Response Time Monitoring (RTTMON) MIB allows users to monitor network performance between the HWIC switch and a remote device
- Virtual LAN
Security Features:
- 802.1X Port-based Network Access Control
- 802.1X Port-based Network Access Control
Protocols:
- TCP/IP
- SNMP v1
- SNMPv2
- SNMPv3
- Telnet
- RMON
- TFTP
- IGMP
- NTP
- STP
- VTP
- CDPv1
- CDPv2
- PPP
- EAP
- OSPF
- HSRP
- TCP/IP
- SNMP v1
- SNMPv2
- SNMPv3
- Telnet
- RMON
- TFTP
- IGMP
- NTP
- STP
- VTP
- CDPv1
- CDPv2
- PPP
- EAP
- OSPF
- HSRP

Media & Performance

Data Transfer Rate:
- 10 Mbps Ethernet Half/Full-duplex
- 100 Mbps Fast Ethernet Half/Full-duplex
- 10 Mbps Ethernet Half/Full-duplex
- 100 Mbps Fast Ethernet Half/Full-duplex
Connectivity Media:
- Category 3 UTP 10Base-T
- Category 4 UTP 10Base-T
- Category 5 UTP 10/100Base-TX
- Category 3 UTP 10Base-T
- Category 4 UTP 10Base-T
- Category 5 UTP 10/100Base-TX

Warranty

Limited Warranty: 90
Additional Warranty Information:
- Product does not ship from original manufacturer
- Product may not be eligible for original manufacturer warranty, rebates or programs
- Direct replacement warranty provided by Ingram Micro (1 year for components, 3 year for systems)
- Product ships from IMSourcing facility within 2-3 days or from stock
- Product may ship in non-standard packaging
- All returns processed directly from IMSourcing
- Product condition subject to availability
- Replacement parts are from our Service inventory and meet our rigorous inspection and quality standards. Some will be new, some are manufacturer certified refurbished, some are considered 'as new' and have been tested, refurbished or remanufactured. All are fully warranted
- Where applicable, -IM indicates an Ingram Micro certified pre-owned product

Environmental Conditions

Humidity:
- 10% to 85% Non-condensing Operating
- 5% to 95% Non-condensing Non-operating
- 10% to 85% Non-condensing Operating
- 5% to 95% Non-condensing Non-operating
Temperature:
- 32°F (0°C) to 104°F (40°C) Operating
- -4°F (-20°C) to 149°F (65°C) Non-operating
- 32°F (0°C) to 104°F (40°C) Operating
- -4°F (-20°C) to 149°F (65°C) Non-operating

Controls/Indicators

Status Indicators:
- Link status
- Inline power
- Link status
- Inline power

Extended Details
