APC Products
Part #: SURTA1500XL | SKU: 125674

Products and parts from APC.

APC Products

Part Details: APC SMART-UPS RT 1500VA (120V) - 1500VA/1050W - 8.6 Minute Full Load - 6 x NEMA 5-15R - Battery/Surge-protected

Need a different version of the APC Accessory? View all 626 configurations

Additional Information

Manufacturer	No
Model Name	Parts
Product Condition	No

General Information

Product Type: Dual Conversion Online UPS
Product Series: RT
Brand Name: APC
Manufacturer: American Power Conversion Corp
Product Model: SURTA1500XL
Product Name: SMART-UPS RT 1500VA (120V) UPS
Product Line: Smart-UPS

Technical Information

Receptacles: 6 x NEMA 5-15R
Plug/Connector Type: NEMA 5-15P
Cord Length: 6 ft
Bypass Switch: Automatic
Emergency Power OFF: Yes

Physical Characteristics

Height: 3"
Width: 17"
Depth: 22"
Form Factor: Tower
Weight (Approximate): 61 lb
Color: Black

Interfaces/Ports

USB: Yes
Serial Port: Yes
Total Number of Expansion Slots: 1

Other

Package Contents:
- SMART-UPS RT 1500VA UPS
- CD with software
- Documentation CD
- Installation Guide
- RS-232 cable
- USB cable
- User Manual
- SMART-UPS RT 1500VA UPS
- CD with software
- Documentation CD
- Installation Guide
- RS-232 cable
- USB cable
- User Manual
Certifications & Standards:
- BSMI
- CSA
- FCC Part 15 Class B
- UL 1778
Additional Information:
- Supports both Tower and Rack-mountable configurations but does not include rack mounting kit
- Automatic restart of loads after UPS shutdown
- Cold-start capable
- Generator Compatible
- Serial Connectivity

Controls/Indicators

Status Indicators:
- Bypass
- Load bar-graphs
- Battery bar-graphs
- On Line
- On Battery
- Replace Battery
- Overload

Power Description

Load Capacity (VA): 1500 VA
Load Capacity (Watt): 1050 W
Input Voltage: 110 V AC
Output Voltage: 120 V AC
Surge Energy Rating: 540 J
Waveform Type: Sine Wave

Management

Battery Management: Intelligent Battery Management
Alarm:
- On Battery
- Low Battery
- Overload

Battery Information

Backup/Run Time (Half Load): 22.20 Minute
Backup/Run Time (Full Load): 8.60 Minute
Battery Characteristics: Spill-proof, Maintenance-free
Battery Chemistry: Sealed Lead Acid
Hot Swappable: Yes

Environmental Conditions

Temperature: 122°F (50°C)
Thermal Dissipation: 393 BTU/h

Warranty

Limited Warranty: 2 Year

Extended Details
