APC Smart-UPS Series UPS
Part #: SU1400RMXLB3U | SKU: 24305

APC Rack Automatic Transfer Switch , Input: 208V , Input Connections: NEMA L6-20P , Cord Length: 6 feet ( 1.83 meters ) , Output: 208V , Output Connections: NEMA L6-20R

APC Smart-UPS Series UPS

Part Details: Smart-UPS XL 1400VA RM 3U 120V (Black)

Need a different version of the APC Smart-UPS Series Accessory? View all 57 configurations

Additional Information

Manufacturer	No
Model Name	Smart-UPS Series
Product Condition	No

General Information

Product Type: Line-interactive UPS
Product Series: XL
Brand Name: APC
Manufacturer: APC - IMSourcing
Product Name: Smart-UPS XL 1400VA
Product Line: Smart-UPS

Technical Information

Receptacles: 6 x NEMA 5-15R
Plug/Connector Type: NEMA 5-15P
Cord Length: 6 ft
Emergency Power OFF: Optional

Physical Characteristics

Height: 5"
Width: 17"
Depth: 16"
Rack Height: 3U
Weight (Approximate): 70 lb
Color: Black

Interfaces/Ports

Serial Port: Yes
Total Number of Expansion Slots: 1

Other

Package Contents:
- Smart UPS XL 1400VA
- CD with software
- Rack Mounting support rails
- Smart UPS signalling RS-232 cable
- User Manual
- Smart UPS XL 1400VA
- CD with software
- Rack Mounting support rails
- Smart UPS signalling RS-232 cable
- User Manual
Certifications & Standards:
- BSMI
- CSA
- UL 1778
- UL 1449
Additional Information:
- Temperature compensated battery charging
- Automatic restart of loads after UPS shutdown
- Automatic self test
- Boost and Trim Automatic Voltage Regulation (AVR)
- Cold start capable
- Disconnected battery notification
- Predictive failure notification
- Adjustable voltage transfer points
- Adjustable voltage sensitivity
- Safety agency approved

Warranty

Additional Warranty Information:
- Product does not ship from original manufacturer
- Product may not be eligible for original manufacturer warranty, rebates or programs
- Direct replacement warranty provided by Ingram Micro (1 year for components, 3 year for systems)
- Product ships from IMSourcing facility within 2-3 days or from stock
- Product may ship in non-standard packaging
- All returns processed directly from IMSourcing
- Product condition subject to availability
- Replacement parts are from our Service inventory and meet our rigorous inspection and quality standards. Some will be new, some are manufacturer certified refurbished, some are considered 'as new' and have been tested, refurbished or remanufactured. All are fully warranted
- Where applicable, -IM indicates an Ingram Micro certified pre-owned product

Power Description

Load Capacity (VA): 1400 VA
Load Capacity (Watt): 1050 W
Input Voltage: 110 V AC
Output Voltage: 120 V AC
Surge Energy Rating: 800 J
Waveform Type: Sine Wave

Controls/Indicators

Status Indicators:
- On Line
- On Battery
- Replace Battery
- Overload Indicators

Battery Information

Backup/Run Time (Half Load): 23.50 Minute
Backup/Run Time (Full Load): 6.60 Minute
Battery Characteristics: Spill-proof, Maintenance-free
Battery Chemistry: Sealed Lead Acid
Hot Swappable: Yes

Management

Battery Management: Intelligent Battery Management
Alarm:
- On Battery
- Low Battery
- Configurable Delay

Environmental Conditions

Temperature: 113°F (45°C)
Thermal Dissipation: 155 BTU/h
