Adtran Networking Data Networking
Part #: 1200872L1 | SKU: 33056

ADTRAN offers a complete line of ISDN Service Units (ISUs) for terminating basic rate service from PBXs and Central Offices. The ISDN Terminal Adapters are ideal for solutions requiring speeds of 128 Kbps. Some models have built-in NT1 functionality. ADTRAN ISDN Inverse Multiplexers provide additional functionality at rates up to 512 Kbps.

Adtran Networking Data Networking

Part Details: NetVanta Dual T1/FT1 Network Interface Module

Need a different version of the Adtran Networking Accessory? View all 357 configurations

Additional Information

Manufacturer	No
Model Name	Networking
Product Condition	No

General Information

Product Type: Network Module
Brand Name: Adtran
Manufacturer: Adtran
Product Model: 1200872L1
Product Name: NetVanta Dual T1/FT1Network Interface Module
Product Line: NetVanta

Technical Information

Application/Usage: Data Networking

Interfaces/Ports

Interfaces/Ports: 2 x T1/FT1 WAN
Interfaces/Ports Details:
- 2 x RJ-48C T1/FT1 WAN
- 1 x RJ-48C Auxiliary Management

Other

Compatibility:
- NetVanta 3000 series
- NetVanta 4305 Access Routers
- NetVanta 1224R/STR Switches w/integrated router
- NetVanta 3000 series
- NetVanta 4305 Access Routers
- NetVanta 1224R/STR Switches w/integrated router
Package Contents:
- Two T1/E1 Network Interfaces
- Quick Start Guide
- Two 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A)
- Two T1/E1 Network Interfaces
- Quick Start Guide
- Two 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A)
Certifications & Standards:
- NetVanta 3200:
- FCC Part 15, Class B
- EN55022 Class B
- NetVanta 3205:
- FCC Part 15, Class A
- EN55022 Class A
- NetVanta 3305:
- FCC Part 15, Class A
- EN55022 Class A
- NetVanta 4305:
- EN55022 Class A
- EN55024
- EN61000-3-2
- EN61000-3-3
Additional Information:
- Line Code: AMI
- Framing: FAS with optional CRC-4
- Input Signal: 0 to -36 dB (DS1)
- Line Build-Out: 0, -7.5, -15, -22.5 dB
- DS0 Assignment: Programmable
- Clock Source:
- Network
- Internal
- Diagnostics:
- Test pattern generation and detection
- Network loopbacks (local and remote)
- Responds to both Inband and FDL loop codes
- Alarm generation and detection
- Network and user sets of performance data (15 minutes and 24 hours)
- NetVanta 4305 will support 2 Dual T1 NIMs
- Note: Only 1 Dual T1 NIM is supported in the NetVanta 3305

Media & Performance

Data Transfer Rate:
- 1.54 Mbps T1
- 64 Kbps FT1 Per Channel

Warranty

Limited Warranty: 5 Year
