Additional Information
| Manufacturer | Adtran |
|---|---|
| Model Name | Networking |
| Product Condition | No |
General Information
- Product Type: Interface Module
- Brand Name: Adtran
- Manufacturer: Adtran
- Product Model: 1200862L2#NEBS
- Product Name: NetVanta NEBS T1/FT1 NIM
- Product Line: NetVanta
Technical Information
- Application/Usage: Data Networking
Physical Characteristics
- Dimensions: 2.8" Width x 4.3" Depth
Interfaces/Ports
- Interfaces/Ports: 1 x T1/FT1 WAN
- Interfaces/Ports Details: 1 x RJ-48C T1/FT1 WAN
Other
- Compatibility: Adtran Netvanta 3205 DC
- Package Contents:
- T1/FT1 NEBS Network Interface Module
- Quick Start Guide
- 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A)
- T1/FT1 NEBS Network Interface Module
- Quick Start Guide
- 15-foot RJ-45 to RJ-45 cable (ADTRAN P/N 3125M008@A)
- Certifications & Standards:
- NEBS Level 3
- GR-63-CORE
- GR-1089-CORE
- UL/CUL 60950
- AT&T TR 62411
- AT&T TR 65016
- ANSI T1.403
- Bellcore TR 194
- Additional Information:
- Input Signal: 0 to -36 dB (DS1)
- Line Code: AMI or B8ZS
- Framing: D4 (SF) or ESF
- FT1 Line Rate: DS0 channelized (multiples of 64 kbps)
Management & Protocols
- Protocols:
- HDLC
- MPPP
- PPP
- Frame Relay
Environmental Conditions
- Humidity: Up to 95% Non-condensing Relative Humidity
- Temperature:
- 32°F (0°C) to 122°F (50°C) Operating
- -4°F (-20°C) to 158°F (70°C) Storage
Media & Performance
- Data Transfer Rate: 1.54 Mbps T1
